Obsidiana Volcano PearlTM
THE ETHICAL BEAUTY
pulido / glacé
| Property | Units of measurament | Quartz Obsidiana |
| Fire reaction UNE-EN-ISO 9239-1:2002 & ISO 1716:2002 | Euroclassses | A2fl s1 |
| Coefficient of linear thermal expansion UNE EN 14617-11 | ºC-1 | 1,2 x 10-5 |
| Flexural strength UNE EN 14617-2 | MPa | 40 – 60 |
| Scratch resistance UNE EN 101:1984 | Mohs | 6 |
| Impact resistance UNE EN 14617-9 | J | min 2,8 (12 mm) min 5,5 (20 mm) |
| Slip resistance UNE EN 14231: 2003 | USRV | Polish: 5 wet / 40 dry Matt: 10 wet / 55 dry |
| Abrasion resistance UNE-EN 14617-4 | mm | 29 – 32 |
| Water absorption UNE EN 14617-1 | % | 0,04 – 0,06 |
| Apparent density UNE EN 14617-1 | g/cm3 | 2250 – 2350 |
| Chemical resistance UNE EN 14617-10 | C4 | C4 (material keeps at least 80 % of the reflection reference value after 8h of basic attack) |
The values in this data sheet are only typical values and not vinculant. For more information or test reports please contact our quality department.
Caractéristiques techniques
Applications
Applications
Dimensions
Certificats de Qualité
 | Certificate for the quartz product range referring to building and construction products according to fire resistance classes, as tested by AFITILICOF, Center for Fire Testing and Research (Association for the Promotion of Research and Fire Safety Technology) pursuant to IMO Resolution A.653 as per IMO FTPC Code Resolution MSC 61 (67). |
 | Contact with Food Certificate COMPAC Technological Quartz products comply with European Regulation CE 1935/2004 for objects intended for contact with food. |
 | Greenguard mark This certificate issued by the Greenguard Environmental Institute guarantees that COMPAC products comply with indoor air quality standards covering volatile organic compounds (VOCs). The seals granted are Greenguard Indoor Air Quality Certified and Greenguard Children & Schools Certified, with the latter being one of the strictest standards in the industry. |
 | NSF Certification NSF Certification, from a recognized non-profit organization in the United States certifying public health, safety and environmental standards, means that COMPAC products are safe and hygienic materials for use in direct contact with food and foodstuffs of all kinds. |
 | The U.S. Green Building Council (USGBC) is transforming the way we design, build, maintain and operate our buildings, homes and communities.USGBC is committed to a prosperous and sustainable future through cost-efficient and energy-saving green buildings. |
 | Cradle to Cradle Certified™ Bronze, a certificate that guarantees the sustainable characteristics of this innovative material created from 100% recycled glass. An international recognition that evaluates the products and their manufacturing process to ensure that the premises of the circular economy are met. |
 | IQ Circular Science, the responsible sense of COMPAC, the philosophy of respect for the environment that we have been working on for years. All of our portfolio designs are produced sustainably with 100% renewable energy and 98% of the water used in the production process is recycled. In addition, IQ Circular Pro includes recycled raw materials. Similarly, all designs contain little or no Respirable Crystalline Silica (RCS). |
 | HPD CERTIFICATE. Health Product Declaration® (HPD) Collaborative is an association representing the full spectrum of the building industry which certificates improvements in product information transparency and material health in buildings and the environment. |
 | Environmental Product Declarations (EPDs). Environmental Product Declarations (EPDs) present relevant and verified environmental information on products and services over their entire life cycle. |
Certificats De Qualité
Documents techniques
- Obsidiana Catalogue 2024 (English) Télécharger
- Manuel de conception et d'installation de comptoirs 2022 (English) Télécharger
- Recommandations techniques d'installation (English) Télécharger
- Warranty 2022 Télécharger
- Declaration of Perfomance 2022 Family 1: Volcano Cloud, Volcano Dark, Volcano Fog, Vocano Light, Volcano Grey, Volcano Pearl Télécharger
- Cleaning, conservation and maintenance manual 2022 Télécharger
Documents techniques
